Teradek - mobile HD video networking
The Cube™ Decoder is a small, extremely low-power video decoder that pairs ideally with the Teradek Cube™ Encoder. They are designed for placement on small handheld monitors and large HD displays and feature either HDMI or HD-SDI output. Using a Cube™ Decoder eliminates the need for using a PC to receive and decode video.
Cubelets™ Encoder/Decoder Pair
Cube™ Encoder/Decoder pairing is the ideal solution for turnkey on-set video monitoring. Use the Cube™ Encoder to stream HD video over WiFi, then connect the Cube™ Decoder to a small hand-held monitor or a professional field monitor to receive the signal and view video up to 1080p24. Cube decoders are available in both HDMI and HD-SDI versions.
For news gathering the Encoder/Decoder pair allows broadcasters to disconnect from the ENG vehicle, eliminating the need for long cable runs, giving the advantage of freedom of movement to the journalist and cameraman for capturing the critical action.
Cube uses H.264 High Profile (Level 4.1) video compression, which is the most advanced compression algorithm in the world today, and it features a built-in scaler to convert from 1080 to 720, 480 or 240 resolutions. Users can choose a resolution and target bit rate based on the availability of IP bandwidth. Typical bit rates for HD are between 2-4Mbps, and SD bit rates are typically sub-1Mbps. Cube's end-to-end latency is approximately 1/8-1/2 second.*
Cube is tiny (about the size of a pack of cards), uses only 2.5W of DC power, weighs about 200g, and mounts easily to a rail system, cage, hotshoe, or camera baseplate. Cube's line-of-sight WiFi range is approximately 300 feet when used with a high quality WiFi access point. Cube has been tested extensively with RED ONE**, Arri Alexa, Panavision Genesis, Canon 5Dii, Canon 7D, various handi-cams and more.
*Latency measured by independent third party testers. iPad's
native video decoder adds approximately 10 seconds of latency. An RTP solution
for iPad will be available shortly to eliminate the latency issue.
**Cube is not compatible with RED ONE's HDMI output as its output is non-standard. Cube works beautifully with RED ONE's HD-SDI output.
|Teradek Cube encoders||Price|
|CUBE-100 1ch HD-SDI Encoder, wired ethernet output||1195.00|
|CUBE-150 1ch HD-SDI Encoder, Built in 2.4G/5.8G WiFi, mic input, USB||1395.00|
|CUBE-200 1ch HDMI Encoder, wired ethernet output||825.00|
|CUBE-250 1ch HDMI Encoder, Built in 2.4G/5.8G WiFi, mic input, USB||1045.00|
|CUBE-500 1ch Composite video Encoder, wired ethernet output||555.00|
|CUBE-550 1ch Composite Encoder, Built in 2.4G/5.8G WiFi, mic input, USB||695.00|
|Teradek Cube decoders|
|CUBE-300 1ch Decoder, SDI out, wired ethernet input||1125.00|
|CUBE-350 1ch Decoder, SDI out, Built in 2.4G/5.8G WiFi, mic input, USB||1350.00|
|CUBE-400 1ch Decoder, HDMI out, wired ethernet input||695.00|
|CUBE-450 1ch Decoder, HDMI out, Built in 2.4G/5.8G WiFi, mic input, USB||895.00|
|Teradek Cube encoder-decoder pairs|
|CUBE-150/350 1ch HD-SDI Encoder/Decoder Pair, 2.4G/5.8G WiFi, mic input, USB||2495.00|
|CUBE-150/450 1ch HD-SDI Encoder, HDMI Decoder Pair, 2.4G/5.8G WiFi, mic input, USB||2125.00|
|CUBE-250/450 1ch HDMI Encoder/Decoder Pair, 2.4G/5.8G WiFi, mic input, USB||1775.00|
|CUBE-250/350 1ch HDMI Encoder, SDI Decoder Pair, 2.4G/5.8G WiFi, mic input, USB||2125.00|
|Teradek Case - On-Set monitoring and video assist system in a box|
|CASE with a single CUBE-150 Transmitter||2495.00|
|CASE with a CUBE-150 Transmitter & CUBE-350 Receiver||3495.00|
|CASE with two CUBE-150 Transmitters||3895.00|
|CASE with two CUBE-150 Transmitters and a CUBE-350 Receiver||4595.00|
|Teradek BOND - HD Streaming Over Multiple 3G & 4G Networks|
|BOND 3/4G Bonding Solution (Excludes CUBE and MPEG-TS Option)||1795.00|
|Sputnik Linux exec s/w on USB, printed manual (Note : Download FOC)||20.00|
|Preconfigured Sputnik Server on Linux Mini Desktop PC||695.00|
|Preconfigured Sputnik Server on a Rack-Mount Linux PC||1050.00|
|BOND plus CUBE-150 Encoder with MPEG-TS Licence||3550.00|
|Other BOND + CUBE + PC bundles available||enquire|
|Optional software enhancements & accessories|
|CUBE MPEG-TS over IP (TCP or UDP) Software Licence||345.00|
|CUBE UDP Multicast Software Licence||170.00|
|CUBE Remote Proxy Recording Licence (Instant Rushes) for CUBE100,120 & 150||345.00|
|CUBE cables & accessories||enquire|
